Home > Products > Concrete Mixer Truck & Trailer > YKYX-3 Trailer Hydraulic Water Well Drilling Rig 600m

YKYX-3 Trailer Hydraulic Water Well Drilling Rig 600m

  • YKYX-3 Trailer Hydraulic Water Well Drilling Rig 600m
  • YKYX-3 Trailer Hydraulic Water Well Drilling Rig 600m

YKYX-3 Trailer Hydraulic Water Well Drilling Rig 600m

    Unit Price: 2000 USD
    Min. Order: 1 Set/Sets
    Packaging: container
    Productivity: 1000sets/month
    Brand: Yikyui
    Transportation: Ocean,Land,Air
    Place of Origin: China
    Supply Ability: 1000sets/month
    Certificate: ISO,CE,API,IADC
    Port: Shanghai,Qingdao,Guangzhoou

Basic Info

Model No.: YKYX-3

Product Description

Ykyx 3 Trailer Hydraulic 600m Water Well Drilling Rig Machine For Sale Jpg

a. five gears, and the highest speed can reach 1045r/min, improving drill efficiency
b. 53 x 59 drilling rod adopted, high rigidity and strong delivery torque.
c. the machine is equipped with national patent technology---taper clutch, with charactristics of strong transmission troque, easy operation and free maintenance.
d. for the winch, we use large module planetary gear and add supporting frame, greatly increasing hoisting and braking ability of the winch.
e. Vertical spidle are fixed by four groups of bearings to ensure that the rotary machine is rigid enough for gravel layer and other complex geoloical conditions.

Water well drilling rig Applications
YKYX-3 drilling rig is mainly used for geological general investigation and exploration, road and tall buliding foundation exploration, kinds of hole in concrete structure, river levees, civil wells and earth temperature central air-conditioner,etc

The YKYX-3 Trailer Hydraulic Water Well Drilling Rig Technical Features:
1.The drilling rig is equipped with wheeled walking mechanism and hydraulic cylinder props.
The machine is highly mobile,and it is convenient to adjust to horizontal drilling purpose.
2.It is designed with the hydraulic feeding mechanism,with which the improved drilling efficiency is achieved.
3.The drilling rig is equipped with a hydraulic chuck,which can be used to reverse the rod without halting the operation.
and the operation is easy and simple,safe and reliable.
4.Equipped with a pressure gauge at the bottom of the hole to indicate the pressure,which is convenient for real-time monitoring of the operation inside the hole.
5.The lifting tower is hydraulic driven which is convenient and reliable.
6.The electric start is adopted for the diesel engine,which saved much of the laboring cost.
7.The Trailer Machine for Wells Drilling can do Geological Exploration,Mineral Exploration,Construction Pile Driver,Civil Drilling.

Main parameters of Trailier Type Water Well Drilling Rig


Unity machine parameter

Drilling depth

600m

Maximum open hole caliber

260mm

End hole caliber

75mm

Drill rod caliber

50mm

Drilling angle

90~75

Drill weight (No include power)

510 560kg

Unity machine dimensions

2.5×1×1.3 2.5×0.9×1.3m

Spindle

spindle speed

142,285,570r/min

Spindle stroke

450mm

Hoist

Max.single line hoisting capacity

960kg

Single line lifting speed

0.41,0.82,1.64m/s

Tightrope caliber

27m

Mud pump

Type

Horizontal single urn twin-action

Displacement

95/77L/min

Diesle engine

Model s1110 18HP

Electric motor

Y160M-4 11kw 1440r/min

Maximum pressure

1.2Mpa

Work pressure

0.7Mpa

Water inlet caliber

30mm

Water to exit caliber

25mm

Triangle conveyor belt

B1575mm
Trailer Hydraulic 600m Water Well Drilling Rig Machine8 Png

We can also provide you with excellent equipment and overseas service as below,
crawler excavators and wheel excavators, wheel loaders, backhoe loaders and skid steer loaders, road rollers

Water well drilling rig,spare parts,technical guidance and installation training for overseas
DTH Drilling Rig,spare parts,technical guidance and installation training for overseas
Jet Grouting Rig ,spare parts,technical guidance and installation training for overseas
Anchor Drilling Rig,spare parts,technical guidance and installation training for overseas
Jumbo Underground Drill Rig
Percussion Drilling Rig
Horizontal Directional Drilling Rig
Core Drilling Rig
Excavator Mixer Truck Backhoe Loader Road Rollers Forklift with distributor discount price
Rotary Drilling Rig ,Air Compressor and mud pump

Ores Mining Processing Turn-Key Service Solution
